Did a user click a button?

While working on a project I came across a situation where I needed to know if a button was clicked by a user or if it had been triggered by the code.

Lucky for us, the DOM is pretty friendly to us in this instance and offers us some help - the isTrusted property from the Event interface.

Let’s create a simple Ionic app and add in some HTML and Typescript to try it out.

<ion-content>
  <ion-item text-center>
    <ion-label class="ion-text-center">{{ source }}</ion-label>
  </ion-item>

  <br />

  <ion-button id="button" expand="block">
    User click click
  </ion-button>

  <ion-button (click)="onRobotClick()" expand="block">
    Robot click
  </ion-button>
</ion-content>

We have a simple label which will hold the source of our clicks and two buttons.

Let’s now add some typescript code to handle all the different clicks.

export class HomePage implements OnInit {
  source: string;
  constructor() {}

  ngOnInit(): void {
    document
      .getElementById('button')
      .addEventListener('click', (event: Event) => {
        this.setSource(event.isTrusted)
      })
  }

  onRobotClick() {
    document.getElementById('button').click();
  }

  setSource(isTrusted: boolean) {
    this.source = isTrusted ? 'User' : 'Robot'
  }
}

We will add an eventListener on our first button and then monitor what happens with him.

Clicking the button itself will trigger a regular event which we will handle with the event listener and check for the isTrusted property which should be set to true.

If we click the second button we will executed a different function which will grab the element by its id and execute a click which should result in the isTrusted being set to false.

In both cases we will call the setSource function which will get the property and display if a user or robot clicked on the button.

As you can see above, clicking the button directly results in the isTrusted property being true so the app displays, correctly, that a user clicked on the button. Clicking the other button triggers a programmatical click on the HTML element which results in the property being false which is indicated by the label changing to Robot.

As always, you can get the code from github.

That’s it for today.

Until next time,
Happy coding

Regex in a switch statement

While working for a client I recently came across an interesting problem. The routing architecture was designed in a particular way which prevented users from directly accessing a page by using a specific URL to the resource. Users had to click their way through the app to get to a specific user or location.

A square peg and a round hole

This proved to be a challenge when a new requirement came up to allow administrators to send links to managers for individual locations.

The links were in the form of http://foo.bar/location/[locationId]/manage

We were able to generate these links directly but the infrastructure to navigate to them didn’t exist and since the entire code base is going to be rewritten with only the necessary modules first, there wasn’t really an incentive to redo the entire routing architecture.

Trying to square the round hole

The approach taken was to create an http interceptor for the app and only trigger the direct navigation mechanism for very specific URLs.

The first draft of the app had a bunch of if statements which would perform Regex evaluations for each of the specified URLs and return a result only on matches. It worked well enough to fix the problem but we didn’t really liked the way it looked. It looked a little clumsy so we tried cleaning it up a bit and ended with a nicer solution.

The solution

Instead of using if statements we wrapped everything up in a switch statement.

getRedirectPage(part: string) {
   switch (true){
       case /location\/\d+\/manage/.test(part):
           return 'LocationManagePage';
       case /user\/\d+\/profile/.test(part):
           return 'UserProfilePage';
       default:
           return '';
   }
}

The return value of the .test() function is of type boolean and only one of the expressions will (or should) return true and match the control value passed to the switch statement which in turn executes a specific block of code which returns the correct page to navigate to.

More often than not, this will be just syntactic sugar, even though switch statements can be more optimized than if statements (link), in our case the performance will pretty much be identical.

Next time we will look into one big performance issue in Angular and Ionic applications - having function calls inside the HTML template and discuss some solutions to this problem.

Until then,
Happy coding

Adding custom colors to your Ionic app

I would have thought that a global pandemic would slow things down for me but I had more work to do than ever which is a nice problem to have I guess :)
Writing blog posts had to go on a brief pause but after a quick two week break I am ready to try to get you excited about the ease of use in Ionic.
Since it’s quite hot in the northern hemisphere, the next few posts are all going to be light and won’t require a lot of brain power to process ;)

The problem

Ionic comes with a few built in colors but every now and then you run into the issue that you need to add one special color to make your app shine again. You can either change one of the predefined ones, especially if it’s a color that defines your app, or you can create a whole new color and use it later.

Changing one of the built in colors is easy as you just have to go into the theme folder and fiddle around with one of them. However, there is a limited number of candidates for that. Yo can pretty much only change primary, secondary, and tertiary because the remaining colors (success, warning, danger, dark, medium, and light) already have a pretty strict semantic meaning and adding a green hue to a warning color, for example, can lead to potential issues down the road.

Let’s check out how to solve this in a more elegant way.

The solution

The easiest way you can get a full color definition is to go to the Ionic colors documentation and define your new color.

I have given my color the name Crojach and selected a nice shade of light blue (I am partially color blind so give me a break here :)

Once you select the color you want, you will see some auto generated scss code below similar to this

:root {
  --ion-color-crojach: #4edfe9;
  --ion-color-crojach-rgb: 78,223,233;
  --ion-color-crojach-contrast: #000000;
  --ion-color-crojach-contrast-rgb: 0,0,0;
  --ion-color-crojach-shade: #45c4cd;
  --ion-color-crojach-tint: #60e2eb;
}

.ion-color-crojach {
  --ion-color-base: var(--ion-color-crojach);
  --ion-color-base-rgb: var(--ion-color-crojach-rgb);
  --ion-color-contrast: var(--ion-color-crojach-contrast);
  --ion-color-contrast-rgb: var(--ion-color-crojach-contrast-rgb);
  --ion-color-shade: var(--ion-color-crojach-shade);
  --ion-color-tint: var(--ion-color-crojach-tint);
}

It’s important to stick everything generated into your code, otherwise it won’t work.

The first part is just a new color definition. It defines the HEX and RGB colors as well as the contrast colors, shades and tints. It’s the same as you would see it for the predefined colors that come with Ionic.

The second, selector, definition is what your color gets translated into by Ionic. Once you set a {Color} to your element, Ionic will add an ion-color-{Color} to that element. It will then check out your css files and apply the required color.

Colors in action

Let’s put it all together now. You can add the color definition anywhere you want. Just make sure it’s referenced.

I have created a new file theme/colors.scss and added the above auto generated code into it.

We then import this file into the global.scss file and are ready to use it in our app.

// theme/colors.scss

:root {
  --ion-color-crojach: #4edfe9;
  --ion-color-crojach-rgb: 78,223,233;
  --ion-color-crojach-contrast: #000000;
  --ion-color-crojach-contrast-rgb: 0,0,0;
  --ion-color-crojach-shade: #45c4cd;
  --ion-color-crojach-tint: #60e2eb;
}

.ion-color-crojach {
  --ion-color-base: var(--ion-color-crojach);
  --ion-color-base-rgb: var(--ion-color-crojach-rgb);
  --ion-color-contrast: var(--ion-color-crojach-contrast);
  --ion-color-contrast-rgb: var(--ion-color-crojach-contrast-rgb);
  --ion-color-shade: var(--ion-color-crojach-shade);
  --ion-color-tint: var(--ion-color-crojach-tint);
}

// global.scss

...
@import "./theme/colors.scss"

// home.page.html
<ion-header>
    <ion-toolbar>
        <ion-title>
            Colors
        </ion-title>
    </ion-toolbar>
</ion-header>
<ion-content>
    <div id="container">
        <ion-button color="crojach">
            Look how pretty I am
        </ion-button>
    </div>
</ion-content>

Once you run the app you will see something like this

It’s not the prettiest button (whatever the label says) but it’s a quick and easy way to generate more variety in your app.

Just keep in mind no to go overboard with the number of colors :)

As always, the full code is on Github.

Until next time,
Happy coding

Creating reusable components

Just as the coronavirus outbreak taught us to isolate ourselves for our own benefit as well as for the benefit of everyone around us, isolating parts of your code can give you a lot of benefits:

• smaller code

• bugs only in one place

• no code duplication

• better code structure

Creating a component and (re)using is very simple.

In this tutorial, we will create a component that will mock publishing the current page to social media.

Creating the app

Let’s create a new Ionic Capacitor app and add a folder named components inside the app folder.

> ionic start components blank

Once you are done with adding the folder your project structure will look like this

...
 src
   app
     components
...

Let’s now create a component using by using the Ionic CLI

Generating the component

> ionic generate component components/social-share

This will create all the needed files (.html, .scss, and .ts) and we are ready to add functionality to our component!

// social-share.component.html

<ion-button (click)="onShareClick()">
  <ion-icon
    slot="icon-only"
    name="share-social-outline">
  </ion-icon>
</ion-button>

// social-share.component.ts

import { Component, Input } from '@angular/core';

@Component({
  selector: 'app-social-share',
  templateUrl: './social-share.component.html',
  styleUrls: ['./social-share.component.scss'],
})
export class SocialShareComponent {
  @Input() currentPage: string;

  constructor() { }

  onShareClick() {
    alert(`Sharing ${this.currentPage} to the world!`);
  }
}

Now that we have a basic component that uses the @Input() currentPage to know from where it has been called there are just two more things to be done.

Creating a components module

In order to use the component, it has to be declared inside one (and only one) module. If you plan to use a component just on a single page it makes sense to declare it inside that page’s module. However, we expect this component to be used across the app so we will create a components module from which then other parts of our application can use this specific component.

// components.module.ts

import from '@angular/core';
import from '@ionic/angular';

import from './social-share/social-share.component';

const components = [
  SocialShareComponent
];

@NgModule({
  imports: [
    IonicModule
  ],
  declarations: components,
  exports: components
})
export class ComponentsModule { }

Using the component

Let’s open our home.page.html file and add the component.

// home.page.html

<ion-header [translucent]="true">
    <ion-toolbar>
        <ion-title>
            Components
        </ion-title>
    </ion-toolbar>
</ion-header>

<ion-content>
    <app-social-share currentPage="Home"></app-social-share>
</ion-content>

The element app-social-share is the one we have defined as the selector for our component in the social-share.component.ts file. Keep in mind that you can name the selector anything you want but you should stay away from keywords like button, div, etc. Now we only need to run the app and try it out.

> ionic serve

If you followed everything you should now see a blank screen. By opening up the developer console you will see the following message

ERROR Error: Uncaught (in promise): Error: Template parse errors:
'app-social-share' is not a known element:
1. If 'app-social-share' is an Angular component, then verify that it
is part of this module.
2. If 'app-social-share' is a Web Component then add
'CUSTOM_ELEMENTS_SCHEMA' to the '@NgModule.schemas' of this
component to suppress this message. ("

<ion-content>
    [ERROR ->]<app-social-share></app-social-share>
</ion-content>
"): ng:///HomePageModule/HomePage.html@9:1
Error: Template parse errors:
'app-social-share' is not a known element:
1. If 'app-social-share' is an Angular component, then verify that
it is part of this module.
2. If 'app-social-share' is a Web Component then add
'CUSTOM_ELEMENTS_SCHEMA' to the '@NgModule.schemas' of this
component to suppress this message. ("

<ion-content>
    [ERROR ->]<app-social-share></app-social-share>
</ion-content>
"): ng:///HomePageModule/HomePage.html@9:1

We get this error message because we didn’t include the ComponentModule into our HomeModule and as a result the HomeComponent has no way of knowing how to render our app-social-share element.

Let’s fix this quickly by adding it.

@NgModule({
  imports: [
    ...
    ComponentsModule
  ],
  ...
})
export class HomePageModule {}

Rerunning the app now will display the button and clicking on the it will execute the click event handler with a simple share function.

To end this blog post on a high note (and learn a little more) while still staying on the topic of self isolation and quarantines I thought it might be fun to learn about the origin of quarantines. Instead of me writting another post about it I’ll just drop a line from the CDC’s website.

“The practice of quarantine, as we know it, began during the 14th century in an effort to protect coastal cities from plague epidemics. Ships arriving in Venice from infected ports were required to sit at anchor for 40 days before landing. This practice, called quarantine, was derived from the Italian words quaranta giorni which mean 40 days.”

— Centers for Disease Control and Prevention

As always, you can check out the full code here.

Until next time,
stay healthy.

Using cents for money values

Ever since people mastered counting most of civilization has used a base 10 numbering system thanks to the number of fingers most people have.

The problem

It all good until you have to come up with representations of fractions. Our computers operate in binary so all numbers are represented as 2^x and unfortunately there are only a few fractions that can accurately be represented like that: 0, 0.25, 0.5, 0.75, and 1.

For all other numbers, there will be an error in their representation which usually isn’t a problem since those small amounts will just get rounded away but if you perform a lot of operations those small errors will add up.

Let’s look at just 2 small examples:

Let’s say you are selling an article for $1.10 and a customer wants to buy 12 of them.
A human would calculate this as 12 * $1.10 = $13.20 and would be done with it while a computer would give you 13.200000000000001.

Now that’s not nice! It isn’t terrible either because you can fix it with a simple rounding procedure.

The second example we can have a look at is the following. You have upgraded your manufacturing process and can sell them now for $0.83. Let’s just calculate how much you have saved your customers per article. $1.10 - $0.83 = $0.27. Nice! The computer however thinks that your savings are actually $0.27000000000000013.

This, again, is something we could live without.

Simple solution

Represent all of your money values as cents or minor values of your currency.

Selling 12 items of $1.10 items would be 12 * 110 = 1320 and a simple conversion would bring this back to $13.20. Since you are dealing with integer numbers the entire problem with floats goes away and you are safe from potential miscalculations.

Another benefit in using integers over floats is that they are in general faster for the computer to work with so if you are working on applications that do a lot of calculations, you might see an improvement in this department as well.

Until next time, happy coding

Using environments in Ionic

Why?

While developing apps you usually don’t want to hook them right into a production environment. Accessing public APIs and manipulating them might hurt your user experience. Maybe you don’t even want to target your public API but an API running locally on your computer.

The list why you want to have different environments is pretty much endless and there are a lot of techniques on how to achieve this.

How (not) to do it.

One of the easiest ways you can achieve this is by having a isProduction flag running through your app.

It would look something like this:

showMessage(): string {
  const message = isProduction
    ? 'Production'
    : 'Development';

  return message;
}

This is easy and works well for small applications like proof-of-concepts apps or applications you have to ship right away and fix later (I know you hate and publish them at the same time).

Another drawback of this approach is your code being very hard to extend.

Imagine the same app now two to three years into development. You have a lot of features and to have a proper staging environment to test stuff out before it is released to users.

showMessage(): string {
  const message = isProduction
    ? 'Production'
    : isStaging
        ? 'Staging'
        : 'Development';

  return message;
}

Imagine doing this over and over again. Adding another environment would likely cause you to question your sanity, buy 30 sheep and move to a forest with your dog and say goodbye to civilization.

Doing it right.

After you create your app in Ionic you will find (as in any Angular project) an environments folder with two files in it

...
environments
 | environment.prod.ts
 | environment.ts
...

Let’s add the above message to our environment files:

// environment.prod.ts
export const environment = {
  message: 'Production'
};

// environment.ts
export const environment = {
  message: 'Development'
};

Using this now in your code is simple:

// home.page.html
<div id="container">
    Your app is running in: <strong> {{ showMessage() }}</strong>
</div>

// home.page.ts
import { environment } from './../../environments/environment';

...

showMessage(): string {
    return environment.message;
}

Let’s now start the app in both environment setups:

//development
> ionic serve

//production
> ionic serve --prod

Now we can check out the results below:

With just one line of code you are able to change a lot of your apps behaviour! Angular and Ionic come with those two environment files by default. If you need more, don’t worry, it’s a very simple process.

We add another file into our environments folder and name it environment.staging.ts with the following content

// environment.staging.ts
export const environment = {
  message: 'Staging'
};

Now that this is done we need to let our CLI know that this file exists and when to use it. For this we have to update the angular.json file.

First, find the architecture peoperty and under configurataions add your fileReplacement stragegy

"configurations": {
  "production": {
    ...
  },
  "staging": {
     "fileReplacements": [
       {
          "replace": "src/environments/environment.ts",
          "with": "src/environments/environment.staging.ts"
        }
     ]
  },
}

Second, we have to do the same under the serve property

"serve": {
  "builder": "@angular-devkit/build-angular:dev-server",
    "options": {
      "browserTarget": "app:build"
    },
    "configurations": {
      "production": {
        "browserTarget": "app:build:production"
      },
      "staging": {
         "browserTarget": "app:build:staging"
      }
    }
}

Now simply run the following command

> ionic serve --configuration staging

And you should see something like this:

Hope this will help you out and prevent a lot of headache.

As always, you can find the code on my GitHub account.

Happy coding!

Ionic 4 - ion-skeleton-text

Over the years, a lot has been said about bounce rate. In essence, you want as many people as possible to stay on your app/page for as long as possible.

One tactic you really should employ is to create something that is engaging for your users. The more they like your content, the more likely is it they will keep coming back - and stay longer.

One problem with that is the more people you compel to give you their time, the harder it becomes for your system to handle all that traffic.

You start improving your system to stay under some magical threshold of 3 seconds and all is looking good. Your app loads fast, doesn’t crash and overall performs as you want it to.

But there is always something extra you can do to can do to shorten the time from app start to app use for your user even if it’s just perceived as being shorter.

Let there be code

Let’s create a blank Ionic project and check a cool new feature in Ionic 4 - ion-skeleton-text.

> ionic start ion-skeleton-text blank

Let’s now go into the home.page.html file and add the content

<!-- home.page.html -->
<ion-content>
  <ion-list>
    <ion-item *ngFor="let item of items">
      {{ item }}
    </ion-item>
  </ion-list>
</ion-content>

We also need some content which we will display with some delay.

// home.page.ts
export class HomePage implements OnInit {
  items: Array<string>;
  constructor() {}

  ngOnInit(): void {
    setTimeout(() => {
      this.items = [
        'Berlin',
        'Buenos Aires',
        'Madrid',
        'New York',
        'Paris',
        'Sydney',
        'Tokyo'
      ];
    }, 2500);
  }
}

If you now execute

> ionic serve

you will see something like this

No loading indication

Adding a loading screen

In order to let the user know that something is going on in the background, we could add a loading indicator which we would remove once the data has been loaded.

// home.page.html
export class HomePage implements OnInit {
  items: Array<string>;
  constructor(private loadingController: LoadingController) {}

  ngOnInit(): void {
    this.loadData();
  }

  async loadData(): Promise<void> {
    const loading = await this.loadingController.create({
      message: 'Loading cities...'
    });

    await loading.present();

    setTimeout(() => {
      this.items = [
        'Berlin',
        'Buenos Aires',
        'Madrid',
        'New York',
        'Paris',
        'Sydney',
        'Tokyo'
      ];

      loading.dismiss();
    }, 2500);
  }
}

I won’t go into the fact that displaying a loading screen should be handled separately because that’s not the point of this post but I know you would never push code like this ;)

Now if we save and check out our browser again we will see a nice loading screen.

Loading screen

Let’s make it a little better

One thing that we know about loading screens is that we don’t really like them. Loading screens on games, apps or anywhere else is something that starts to annoy us quite quickly so we have to keep them as short as possible or remove them completely.

We can try to trick people into believing that the app is already in the process of displaying some content when in fact it’s still waiting for the server to respond. In some cases, it’s just enough to let your users feel like the app is working to make them happy.

“When you are courting a nice girl an hour seems like a second. When you sit on a red-hot cinder a second seems like an hour. That’s relativity”

— Albert Einstein

If we can display to the user something to keep them happy until they get what they came for we can keep them engaged for longer.

ion-skeleton-text is the answer

ion-skeleton-text is a new UI component which displays a placeholder content instead of the true one.

Implementing it is very straight-forward as you will see soon. Let’s dive right into it.

<!-- home.page.html -->
<ion-content>
  <ion-list *ngIf="items; else skeleton">
    <ion-item *ngFor="let item of items">
      {{ item }}
    </ion-item>
  </ion-list>
</ion-content>

<ng-template #skeleton>
  <ion-list>
    <ion-item *ngFor="let item of [50, 20, 70, 80, 50]">
      <p [ngStyle]="{ width: item + '%' }">
        <ion-skeleton-text animated></ion-skeleton-text>
      </p>
    </ion-item>
  </ion-list>
</ng-template>

What we do here is to simply show the items once they are set (after the 2500 ms) while displaying a few placeholder items in the mean-time.

We also got rid of the loading screen code again in the home.page.ts file to make it look like it was before.

// home.page.ts
export class HomePage implements OnInit {
  items: Array<string>;
  constructor() {}

  ngOnInit(): void {
    this.loadData();
  }

  async loadData(): Promise<void> {
    setTimeout(() => {
      this.items = [
        'Berlin',
        'Buenos Aires',
        'Madrid',
        'New York',
        'Paris',
        'Sydney',
        'Tokyo'
      ];
    }, 2500);
  }
}

Now if you save all you will see something like this:

Skeleton text

This looks a lot more dynamic than having just a simple spinner and loading message. If you are displaying complex data you can even take advantage of two other cool Ionic component - ion-avatar and ion-thumbnail.

Let’s create one final skeleton-text item which will represent some more complex data.

<!-- home.page.html -->
<ion-content>
  <ion-list *ngIf="items; else skeleton">
    <ion-item *ngFor="let item of items">
      <ion-thumbnail slot="start">
        <img [src]="item.image" />
      </ion-thumbnail>
      <ion-label>
        <h3>City: {{ item.city }}</h3>
        <p>Country: {{ item.country }}</p>
        <p>Population: {{ item.population }}</p>
      </ion-label>
    </ion-item>
  </ion-list>
</ion-content>

<ng-template #skeleton>
  <ion-list>
    <ion-item *ngFor="let item of [1, 2, 3, 4, 5]">
      <ion-thumbnail slot="start">
        <ion-skeleton-text animated></ion-skeleton-text>
      </ion-thumbnail>
      <ion-label>
        <h3>
          <ion-skeleton-text animated style="width: 50%"></ion-skeleton-text>
        </h3>
        <p>
          <ion-skeleton-text animated style="width: 80%"></ion-skeleton-text>
        </p>
        <p>
          <ion-skeleton-text animated style="width: 60%"></ion-skeleton-text>
        </p>
      </ion-label>
    </ion-item>
  </ion-list>
</ng-template>

The typescript code has change also a little:

export class HomePage implements OnInit {
  items: Array<any>;
  constructor() {}

  ngOnInit(): void {
    this.loadData();
  }

  async loadData(): Promise<void> {
    setTimeout(() => {
      this.items = [
        { city: 'Berlin', country: 'Germany', population: '3.5 million', image: '...' },
        { city: 'Buenos Aires', country: 'Argentina', population: '15 million', image: '...' },
        { city: 'Madrid', country: 'Spain', population: '3.3 million', image: '...' },
        { city: 'New York', country: 'USA', population: '19.5 million', image: '...' },
        { city: 'Paris', country: 'France', population: '2.2 million', image: '...' },
        { city: 'Sydney', country: 'Australia', population: '5.4 million', image: '...' },
        { city: 'Tokyo', country: 'Japan', population: '9.2 million', image: '...' }
      ];
    }, 2500);
  }
}

The final result looks now like this:

A more complex example

Now that’s pretty, isn’t it?

The ion-skeleton-text UI component can add a little twist to your app and give the user something shiny to look at while your app does all the heavy lifting. It will keep them focused on something until the final content loads fully and you are able to display it. Giving the user the feeling that the app is running instead of waiting will make them come back and will give you more users to serve.

If you want to check out the code, have a look at it here.

Until next time,
happy coding.

Simple multi level menu in Ionic/Angular

While working on a project, a new requirement emerged where the client wanted to have a multi level menu displayed. After some digging around I didn’t find anything that was simple enough. Pretty much all of them were using some kind of id + level tags on menu items which then helped them know if they should expand something or not.

I like to keep things as simple as possible so I tried to take advantage of Angular’s component system and build something a little easier to understand.

Hello world (kind of)

Let’s first create an Ionic app with a predefined side menu and move from there. You just need to run this command in your terminal and Ionic will do the rest.

> ionic start multilevel-menu sidemenu

Now you can start your app with the following command

> ionic serve

This will start your (default) browser and you should see something like this:

What we start with

Looks nice, but nothing too exciting.

1. Housekeeping

Before we start, let’s remove a bunch of things before we start. Let’s remove everything referencing list. Remove the entire list folder as well as all of it’s traces from the app.components.ts and app-routing.module.ts files. If you rerun ionic serve now, you will see just a single home menu item.

2. Creating a model

What better thing to have as a model for our multi level menu than a restaurant menu. Unfortunately, restaurant menus can get quite complicated but it will serve our needs perfectly.

We will create a very simple model with just three properties: name, id, and children. Create a new folder inside the app folder and name it models. Add another file, named menu-item.ts into it.

//src/app/models/menu-item.ts

export class MenuItem {
  name: string;
  id: number;
  children: Array<MenuItem>;
}

3. Creating some data

Based on this model, let’s creating some data for our app to use. We will create another folder named data inside the assets folder and add a new menu-items.ts file into it with the following content

//src/assets/data/menu-items.ts

export const menuItems = [
  {
    name: 'Appetizers',
    id: 1,
    children: [
      {
        name: 'Fresco Salsa',
        id: 6,
        children: null
      }
    ]
  },
  {
    name: 'Main dishes',
    id: 2,
    children: [
      {
        name: 'Beef',
        id: 7,
        children: [
          {
            name: 'Crispy Orange Beef',
            id: 10,
            children: null
          }
        ]
      },
      {
        name: 'Burger',
        id: 8,
        children: [
          {
            name: 'Chorizo Burger',
            id: 11,
            children: null
          }
        ]
      },
      {
        name: 'Vegetarian',
        id: 9,
        children: [
          {
            name: 'Chile Rellenos',
            id: 12,
            children: null
          }
        ]
      }
    ]
  },
  {
    name: 'Side dishes',
    id: 3,
    children: [
      {
        name: 'Baked potato',
        id: 13,
        children: null
      }
    ]
  },
  {
    name: 'Salads',
    id: 4,
    children: [
      {
        name: 'Taco Slaw',
        id: 14,
        children: null
      }
    ]
  },
  {
    name: 'Desserts',
    id: 5,
    children: [
      {
        name: 'Crepes',
        id: 15,
        children: null
      }
    ]
  }
];

It’s a mix of everything, so I hope there is something for you in this menu as well!

4. Final work before the good stuff

The last thing we have to do is go back to our app.component.ts and replace appPages with our new menuItems

//src/app/app.component.ts

import { menuItems } from '../assets/data/menu-items';

// ...

export class AppComponent {
  private menu = menuItems;
  // ...
}

The last thing we have to do is to remove the old markup used to render the menu and replace it with something simpler (for now). Let’s go into the app.component.html file and do that right now.

<!--src/app/app.component.html-->

<ion-menu-toggle auto-hide="false" *ngFor="let menuItem of menu">
  <ion-item>
    {{menuItem.name}}
  </ion-item>
</ion-menu-toggle>

Saving everything you should see your new menu in all it’s glory.

The first level of menu items

It’s pretty, isn’t it?

5. Brainstorming

Let’s think about how we are going to proceed here. From the model we can see that we have a menu item that can hold a bunch of menu items and so on.

What we will do then is to create a component which will pass its children to another component of the same type.

If the current component doesn’t have any children it’s a dish and we will display a simple button for the user to tap on, otherwise it’s just a category and we will display it differently.

6. Creating the component

If you are like me you don’t know all the bits and pieces a component needs right away. Lucky for us Ionic and Angular have us covered. Just switch to your terminal and type in the following command

> ionic g c menu-item

This will tell the Ionic (and underlying Angular) CLI to g(enerate) a new c(omponent) named menu-item.

We, also, need to let Ionic know about our new component so we will add it into the declarations array of the app.module.ts file.

//src/app/app.module.ts

import { MenuItemComponent } from './menu-item/menu-item.component';

// ...

@NgModule({
  declarations: [AppComponent, MenuItemComponent],

  /// ...
}

Let’s change the markup in app.component.html file to use the new component:

<!--src/app/app.component.html-->

 <ion-menu-toggle auto-hide="false" *ngFor="let menuItem of menu">
   <!-- <ion-item>
     {{menuItem.name}}
   </ion-item> -->
   <app-menu-item></app-menu-item>
 </ion-menu-toggle>

Saving it all now will result in this:

Looks like my CS degree is paying off

There is one last step until we can call it a day…

7. Finishing the component

As we discussed above, if the current menu item has children, we want it to display its name and pass its children down to another component of the same type. If there are no children, display a button which the user can click.

The final component will look something like this:

<!--src/app/menu-item/menu-item.component.html-->

<div>
  <p *ngIf="menuItem.children; else finalItem">
    <ion-button
      [color]="isRoot ? 'primary' : 'secondary'"
      [expand]="isRoot ? 'full' : 'block'"
      (click)="isOpen = !isOpen"
    >
      {{ menuItem.name }}
    </ion-button>

    <span *ngIf="isOpen">
      <app-menu-item
        *ngFor="let item of menuItem.children"
        [menuItem]="item"
      ></app-menu-item>
    </span>
  </p>
</div>

<ng-template #finalItem>
  <p>
    <ion-button color="light" expand="full"
                (click)="onMenuItemSelected(menuItem)">
      {{ menuItem.name }}
    </ion-button>
  </p>
</ng-template>

The trick here is simply to toggle each component’s isOpen property and toggle between showing and hiding the children. Also, if you aren’t familiar with the if - else syntax from here, check out one of my previous posts.

Let’s just clean up the app.component.html a little and we are done

<!--src/app/app.component.html-->

<app-menu-item
  *ngFor="let menuItem of menu"
  [menuItem]="menuItem"
  [isRoot]="true">
</app-menu-item>

The final product will look like this:

Final multile level menu

If you had trouble following along, or just want to see the code fully. You can check it out here.

Until next time,
happy coding.

Adding timestamps to photos

While working on an Ionic project, the client asked for a timestamp to be added at the bottom of a taken photo.

After some head scratching, I ended up with the solution below.

onTakePhoto(): void {
  const options: CameraOptions = {
    quality: 30,
    destinationType: this.camera.DestinationType.DATA_URL,
    encodingType: this.camera.EncodingType.JPEG,
    mediaType: this.camera.MediaType.PICTURE,
    targetWidth: 2304,
    targetHeight: 1728
  };

  this.camera.getPicture(options).then(
    (imageData) => {
    },
    (error) => {
      // not important now
    }
  );
}

generateImageWithTimestamp(dataUrl: string): void {
  let image = new Image();
  image.onload = () => {
    let canvas = document.createElement("canvas");
    let context = canvas.getContext("2d");

    canvas.height = image.height;
    canvas.width = image.width;

    context.drawImage(image, 0, 0);

    //adding some styling
    context.font = "80px Arial bold";
    context.textAlign = "center";
    context.fillStyle = "orange";
    context.fillText(
      this.getTimeStamp(),
      image.width / 2, //center
      image.height * 0.97 //close to the bottom
    );

    const finalImage = canvas.toDataURL("image/jpeg", 1);
  };
  image.src = dataUrl;
}

getTimeStamp(): string {
  const date = new Date();

  return `${date.getDate()}. ${date.getMonth() +1}. ${date.getFullYear()}, ${date.getHours()}:${date.getMinutes()}`;
}

We simply take a photo, redraw it on a canvas where we also add the timestamp.

One thing to keep in mind here is that order is important.

In my first attempt I first added the text and then the image which, of course, has overwritten the text. It looks obvious now but it took me a little to figure it out.

Hope this will help you out.

Until next time,
Happy coding.

Deciphering error messages in Ionic

While working on some projects which use the camera to take pictures inside the app I had to add a description for the user to ask for permission.

The code for that is pretty simple:

<edit-config file="*-Info.plist" mode="merge" target="NSPhotoLibraryUsageDescription">
   <string>Please let me take pictures</string>
</edit-config>

After that I wanted to build the application for iOS with the following command:

ionic cordova build ios

What usually finished after 10 seconds with a success message now ended like this:

Now that’s what I call an error message!

If you are like me you would have no idea what this means. Trying to build again doesn’t solve the problem so it has to be something with this particular change.

After a little bit of digging around I found the fix.

Go into the platforms folder and into ios. There you will find ios.json which holds configurations for the entire application. Locate *-Info.plist and delete the entire object.

After that simply run:

ionic cordova prepare ios

Your build will work again and you can get on with finish your app.

Hope this helps.

Until next time,
happy coding.
